Bose PowerShare PS602P Service Manual

90
Diodes
ELECTRICAL PART LIST
Front Panel PCB Assembly, PS604
Reference
Designator
Description
V
endor Part
Number
Note
D900 LED, SP, 3X5, RD/GN, SUPER WHITE, DIFFUSED,
EVERLIGHT
3700-2861
D901 LED, SP, 3X5, RD/GN, SUPER WHITE, DIFFUSED,
EVERLIGHT
3700-2861
D902 LED, SP, 3X5, RD/GN, SUPER WHITE, DIFFUSED,
EVERLIGHT
3700-2861
D903 LED, SP, 3X5, RD/GN, SUPER WHITE, DIFFUSED,
EVERLIGHT
3700-2861
D905 LED, SP, 3X5, RD/GN, SUPER WHITE, DIFFUSED,
EVERLIGHT
3700-2861
D906 LED, SP, 3X5, RD/GN, SUPER WHITE, DIFFUSED,
EVERLIGHT
3700-2861
D907 LED, SP, 3X5, RD/GN, SUPER WHITE, DIFFUSED,
EVERLIGHT
3700-2861
D908 LED, SP, 3X5, RD/GN, SUPER WHITE, DIFFUSED,
EVERLIGHT
3700-2861
D909 LED, SP, 3X5, RD/GN, SUPER WHITE, DIFFUSED,
EVERLIGHT
3700-2861
Integrated Circuits
Reference
Designator
Description
V
endor Part
Number
Note
U900 IC, EXTEND, 74HC4094, SO16 3132-4431
U901 IC, EXTEND, 74HC4094, SO16 3132-4431
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
J900 WIRE-CONN, 10P, P2.0, #26, UL1007, 485, RD/WH,
F/M, HST
7013-4910
J901 BRACKET, GROUND, BRASS, T=0.8, TIN, PLATED 4132-6223
