Bose PowerShare PS602P Service Manual

38
ELECTRICAL PART LIST
Resistors
SMPS PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description
V
endor Part
Number
Note
R200 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R202 RMG, 1/10W, 3.3K, 1%, 0805 4720-332A
R203 RMG, 1/16W, 3K, 1%, 0603 4723-302A
R204 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A
R205 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991
R206 RMG, 1/10W, 82 OHMS, 5%, 0805 4720-820J
R207 RMG, 1/8W, 330K, 1%, 1206 4721-334A
R208 RMG, 1/8W, 330K, 1%, 1206 4721-334A
R209 RMG, 1/8W, 330K, 1%, 1206 4721-334A
R210 RMG, 1/8W, 330K, 1%, 1206 4721-334A
R211 RMG, 1/8W, 330K, 1%, 1206 4721-334A
R212 RMG, 1/8W, 330K, 1%, 1206 4721-334A
R213 RMG, 1/10W, 91K, 1%, 0603 4720-913A
R214 RMG, 1/10W, 75 OHMS, 5%, 0805 4720-750J
R215 RMG, 1/4W, 200K, 1%, 1206 4725-204A
R216 RMG, 1/8W, 0 OHMS, 1%, 1206 4721-000A
R217 RMG, 1/16W, 30K, 1%, 0603/1608 4723-303A
R218 RMG, 1/8W, 1.5K, 5%, 1206 4721-152J
R220 RMG, 1/8W, 1.5K, 5%, 1206 4721-152J
R221 RMG, 1/8W, 1.5K, 5%, 1206 4721-152J
R222 RMG, 1/10W, 249 OHM, 1%, 0805 4720-249A
R223 RMG, 1/16W, 51K, 1%, 0603/1608 4723-513A
R224 RMG, 1/16W, 56K, 1%, 0603 4723-563AR
R225 RMG, 1/16W, 560K, 1%, 0603/1608 4723-564A
R226 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
R227 RMG, 1/16W, 0 OHMS, 1%, 0603 4723-000A
R228 RMG, 1/10W, 15 OHMS, 1%, 0805 4720-150A
R229 RMG, 1/10W, 15 OHMS, 1%, 0805 4720-150A
R230 RMG, 1/10W, 4.99K, 1%, 0805 4720-4991
R232 RMG, 1/10W, 18K, 5%, 0805 4720-183J
R233 RMG, 1/4W, 100 OHMS, 1%, 1206 4725-101A
R234 RMG, 1/4W, 100 OHMS, 1%, 1206 4725-101A
R235 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R236 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R237 RMG, 1/10W, 750 OHMS, 1%, 0805 4720-751A
R238 RMG, 1/16W, 240 OHMS, 1%, 0603/1608 4723-241A
R239 RMG, 1/16W, 240 OHMS, 1%, 0603/1608 4723-241A
R240 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R241 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R242 RMG, 1/8W, 2.2 OHMS, 5%, 1206 4721-2R2J
R243 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R244 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R245 RMG, 1/8W, 330K, 5%, 1206 4721-334J
R246 RMG, 1/16W, 0 OHMS, 1%, 0603 4723-000A
R248 RMG, 1/8W, 47 OHMS, 5%, 1206 4721-470J
R249 RMG, 1/8W, 47 OHMS, 5%, 1206 4721-470J
R251 RMG, 1/8W, 47 OHMS, 5%, 1206 4721-470J
R252 RMG, 1/8W, 47 OHMS, 5%, 1206 4721-470J
R253 RMG, 1W, 10K, 5%, 2512 4728-103J
R254 RMG, 1/4W, 5.1K, 5%, 1206 4725-512J
R257 RMG, 1/4W, 5.1K, 5%, 1206 4725-512J
R258 RMG, 1/10W, 750 OHMS, 1%, 0805 4720-751A
