Bose PowerShare PS602P Service Manual

39
ELECTRICAL PART LIST
Resistors (continued)
SMPS PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description
V
endor Part
Number
Note
R259 RMG, 1/10W, 750 OHMS, 1%, 0805 4720-751A
R260 RMG, 1/10W, 750 OHMS, 1%, 0805 4720-751A
R261 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991
R262 RMG, 1/16W, 10 OHMS, 1%, 0603 4723-100AR
R263 RMG, 1/16W, 10 OHMS, 1%, 0603 4723-100AR
R264 RMG, 1/16W, 10 OHMS, 1%, 0603 4723-100AR
R265 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R266 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R267 RMG, 1W, 10K, 5%, 2512 4728-103J
R268 RMG, 1/10W, 100 OHMS, 1%, 0805 4720-101A
R270 RMG, 1/16W, 100 OHMS, 1%, 0603 4723-101A
R271 RMG, 1/16W, 100 OHMS, 1%, 0603 4723-101A
R272 RMG, 1/16W, 100K, 1%, 0603 4723-104AR
R273 RMG, 1/16W, 100K, 1%, 0603 4723-104AR
R274 RMG, 1/4W, 200K, 1%, 1206 4725-204A
R275 RMG, 1/16W, 100K, 1%, 0603 4723-104AR
R276 RMG, 1/16W, 100K, 1%, 0603 4723-104AR
R277 RMG, 1/16W, 100K, 1%, 0603 4723-104AR
R278 RMG, 1/16W, 100K, 1%, 0603 4723-104AR
R282 RCF, 1/4W, 100K, 5%, AT 4705-104J
R283 RCF, 1/4W, 100K, 5%, AT 4705-104J
R284 RMG, 1/10W, 10K, 1%, 0805 4720-103A
R285 RMG, 1/16W, 1M, 1%, 0603 4723-105A
R286 RMG, 1/16W, 1M, 1%, 0603 4723-105A
R287 RMG, 1W, 0.33 OHMS, 1%, 2512 4728-R33A
R288 RMG, 1/16W, 16K, 1%, 0603/1608 4723-163A
R289 RMG, 1/16W, 16K, 1%, 0603/1608 4723-163A
R290 RMG, 1/16W, 470K, 1%, 0603 4723-474A
R291 RMG, 1/16W, 2K, 1%, 0603/1608 4723-202A
R292 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
R293 RMG, 1/16W, 12K, 1%, 0603 4723-123AR
R294 RMG, 1/16W, 12K, 1%, 0603 4723-123AR
R295 RWR, 5W, 2.5 OHMS, 5%, SQZ, RL 474B-2R5J
R296 RWR, 5W, 2.5 OHMS, 5%, SQZ, RL 474B-2R5J
R297 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A
R298 RMG, 1/16W, 2K, 1%, 0603/1608 4723-202A
R299 RMF, 3W, 0.025 OHMS, 1%, ATW, NON-INDUCTIVE 471A-R025H
R306 RMG, 1/10W, 220 OHMS, 5%, 0805 4720-221J
R307 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R308 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R309 RMG, 1/8W, 1M, 1%, 1206 4721-105A
R310 RMG, 1/8W, 560K, 1%, 1206 4721-564A
R311 RMG, 1/8W, 560K, 1%, 1206 4721-564A
R312 RMG, 1/16W, 10K, 1%, 0603/1608 4723-103A
R313 RMG, 1/16W, 43K, 1%, 0603/1608 4723-433A
R319 RMG, 1/10W, 56R, 1%, 0805 4720-560A
R320 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R323 RMG, 1/16W, 47K, 1%, 0603 4723-473AR
R324 RMG, 1/16W, 47K, 1%, 0603 4723-473AR
R325 RMG, 1/16W, 47K, 1%, 0603 4723-473AR
R326 RMG, 1/16W, 18K, 1%, 0603/1608 4723-183A
R327 RMG, 1/10W, 56R, 1%, 0805 4720-560A
