Bose PowerShare PS602P Service Manual

40
ELECTRICAL PART LIST
Resistors (continued)
Capacitors
SMPS PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description
V
endor Part
Number
Note
C200 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C201 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C202 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C204 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C205 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C206 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C207 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C208 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C209 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C210 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C211 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C212 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C213 CC, 50V, 120pF, 5%, 0603, C0G 150F-121JAC
C214 CE, 50V, 10uF, 20%, RLT, 5X11, 105C, RX, NOVER 157F-106MIUTU
C215 CC, 25V, 10uF, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C216 CC, 25V, 10uF, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
Reference
Designator
Description
V
endor Part
Number
Note
R328 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R338 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R339 RMG, 1/4W, 200K, 1%, 1206 4725-204A
R340 RMG, 1/4W, 200K, 1%, 1206 4725-204A
R345 RCF, 1/4W, 100K, 5%, AT 4705-104J
R346 RCF, 1/4W, 100K, 5%, AT 4705-104J
R351 RMG, 1/8W, 1.5K, 5%, 1206 4721-152J
R352 RMG, 1/16W, 0 OHMS, 1%, 0603 4723-000A
R353 RMG, 1/8W, 100 OHMS, 1%, 1206 4721-101A
R354 RMG, 1/16W, 100 OHMS, 1%, 0603 4723-101A
R355 RMG, 1/16W, 0 OHMS, 1%, 0603 4723-000A
R356 VARISTOR, 320V, 10%, 6KV, 3KA, 10MM, RL 4735-0016 3
R357 RMG, 1/10W, 45.3K, 1%, 0603 4720-4532
R358 RMG, 1/10W, 4.02K, 1%, 0603 4720-4021
R359 RMG, 1/16W, 44.2K, 1%, 0603 4723-4422
R360 RMG, 1/10W, 4.02K, 1%, 0603 4720-4021
R361 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R362 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R363 RMG, 1/8W, 4.7 OHMS, 1%, 1206 4721-4R7A
R367 RMG, 1/16W, 2K, 1%, 0603/1608 4723-202A
R368 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991
R389 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A
R390 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A
R391 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A
R392 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A
R393 RMG, 1/16W, 3.3K, 1%, 0603 4723-332AR
R394 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R395 RMG, 1/16W, 510 OHMS, 1%, 0603 4723-511A
R398 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
