Bose PowerShare PS602P Service Manual

91
Capacitors
ELECTRICAL PART LIST
Rear Output PCB Assembly, PS602
Inductors
Integrated Circuits
Reference
Designator
Description
V
endor Part
Number
Note
U710 IC, ESD PROTECTION, TPD2E001, SOT533 3132-7831
Reference
Designator
Description
V
endor Part
Number
Note
L950 CHOKE, COMMODE, 40uH, 10%, 10A, TC1305 1805-0450
L951 CHOKE, COMMODE, 40uH, 10%, 10A, TC1305 1805-0450
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
ENCODER702 ENCODER, ROTARY, 10P1T, DC50V, 0.1A, 10X10,
COPAL
5200-509727
ENCODER703 ENCODER, ROTARY, 10P1T, DC50V, 0.1A, 10X10,
COPAL
5200-509727
J711A CONN, PIN, HEADER, 4P, P2.54, ST, M, L=15 2101-3295
J714 USB-B, CONN, F, 4PIN, P2.5, 30V, 1.5A, 12X11, SIL 2113-3428
J750 RJ45, F, 8P, P2.54, 12VAC, 1.5A, 17X16, SIL, ST 2113-3451
J760A CONN, PIN, HEADER, 4P, P2.54, ST, M, L=15 2101-3295
J761A CONN, PIN, HEADER, 4P, P2.54, ST, M, L=15 2101-3295
J950 WIRE-CONN, 4P, P3.96, #18, UL1007, L=300, F/M,
FERRITE
7013-5270
J960 SOCKET, F, 2P, P5.08, 300V, 12A, GRN, ST 2113-3420
J961 SOCKET, F, 2P, P5.08, 300V, 12A, GRN, ST 2113-3420
SW702 SW, DIP, SPST, 24V, 25MA, P2.54, 6P 5200-5077
Reference
Designator
Description
V
endor Part
Number
Note
C950 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C951 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C952 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C953 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C954 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C955 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C956 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C957 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
