37
ELECTRICAL PART LIST
Integrated Circuits (continued)
Reference
Designator
Description Part Numbe
Note
U301 OP AMP, QUAD, JFET, TLE2074, SO16W, 3mV 326336-0040
U302 SWITCH, ANALOG, SPST, ADG452, 16TSSOP 328693-0010
U303 POWER STAGE AMPLIFER, 2X15W, 32HTSSOP 353939-0010
U304 COMPARATOR, QUAD, LM2901, 14SOIC 310919-001
U400 HALL-EFFECT CURRENT SENSOR, ACS711, 8SO 330390-0010
VR100 3 TERM ADJ REG, LM317MQDCYR 271642-001
VR101 3 TERM ADJ REG, LM317MQDCYR 271642-001
VR102 VOLT REG, POS, LDO, 3A, ADJ, LD1085, DPAK 362098-0010
VR103 VOLTAGE REG, NEGATIVE, LM337, SOT-223 328992-0010
Miscellaneous
Reference
Designator
Description Part Numbe
Note
HS100 HEAT SINK, DPAK 320438-002
HS300 HEAT SINK, D2PAK 320438-001
J100 CONN, FFC, 0.5mm, T ENTRY, 20POS, WHT 269863-020
J101 CONN, FFC, 0.5mm, T ENTRY, 10POS, WHT 269863-010
J300 CONN, HEADER, INLINE, PCB MNT, 4P 133220-04
J400 CONN, HEADER, INLINE, 3P, BLACK 133220-103
Y100 OSCILLATOR, 5.6MHz, 25PPM, 3.3V, 3225 757550-5M60000
- HEATSINK, TOP, AMP 732979-0010
- THERMAL PAD, AMP 720281-0010 Qty. 2
- SCREW, M3 X 8MM, SKT HD CAP 473028-0010 Qty. 3
- HEATSINK, BOTTOM, AMP 623674-0010
Amplifier PCB Assembly, PS602/PS602P/PS604
To Next Page
