Bose PowerShare PS602P Service Manual

48
ELECTRICAL PART LIST
Resistors (continued)
Rear Panel PCB Assembly, PS602
Capacitors
Reference
Designator
Description
V
endor Part Number Note
R861 RMG, 1/16W, 1M, 1%, 0603 4723-105A+P
R870 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R871 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R872 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R873 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R882 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R883 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R886 RCFA, 1/16W, 47 OHM X4, 5%, 0603 4703-470J+P-04
R887 RCFA, 1/16W, 47 OHM X4, 5%, 0603 4703-470J+P-04
R888 RCFA, 1/16W, 47 OHM X4, 5%, 0603 4703-470J+P-04
R889 RCFA, 1/16W, 47 OHM X4, 5%, 0603 4703-470J+P-04
R890 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
R891 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
R892 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
R893 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
R894 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
R895 RMG, 1/16W, 100 OHM, 1%, 0603 4723-101A+P
R896 RMG, 1/16W, 100 OHM, 1%, 0603 4723-101A+P
R897 RMG, 1/10W, 0 OHM, 1%, 0805 4720-000A+J
Reference
Designator
Description
V
endor Part Number Note
C700 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C701 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C702 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C703 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C704 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C705 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C710 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C711 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C712 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C713 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C715 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C716 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C717 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C718 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C727 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C728 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C729 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
C730 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
C731 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C732 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C733 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C734 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C735 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C736 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C737 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C738 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C741 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
C743 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
C746 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
