Bose PowerShare PS602P Service Manual

49
ELECTRICAL PART LIST
Capacitors (continued)
Rear Panel PCB Assembly, PS602
Reference
Designator
Description
V
endor Part Number Note
C747 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
C749 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
C750 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
C752 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
C753 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
C776 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C777 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C785 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C786 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C788 CC, 100V, 0.1uF, 10%, 1206, AVX 150H-104K+6-CFD
C789 CC, 100V, 0.1uF, 10%, 1206, AVX 150H-104K+6-CFD
C790 CC, 100V, 0.1uF, 10%, 1206, AVX 150H-104K+6-CFD
C799 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C800 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C802 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C803 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C804 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C805 CC, 50V, 0.1uFF, 10%, 0603, X7R 150F-104K+P-AC
C812 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C813 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C814 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C815 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C816 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C817 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C831 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C832 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C833 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C834 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C846 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C847 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C848 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C849 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C856 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C857 CC, 6.3V, 22uF, 10%, 1206, 3.2X1.6 150B-226K+6-CF
C859 CC, 16V, 0.1uF, 10%, 0603/1608, 1X2 150D-104K+P-AC
C866 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C867 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C868 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C869 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C870 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C871 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C876 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C877 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C878 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C879 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C880 CC, 100V, 0.1uF, 10%, 0805, X7R 150H-104K+J-BD
