Bose PowerShare PS602P Service Manual

50
ELECTRICAL PART LIST
Diodes
Rear Panel PCB Assembly, PS602
Integrated Circuits
Reference
Designator
Description
V
endor Part Number Note
J701 SOCKET, M, 2P, P5, 300V, 15A, BLACK 2113-3361+1
J703 RCA, JACK, F, 2P, P15, 30V, 0.3A, H=10+9.5, R/W 2113-3153+2
J711B CONN, PIN, HEADER, 4P, P2.54, ST, F 2101-3294+0
J717 CONN, HEADER, 6P, P2.54, DIP, ST, M, L=8.54 2101-3393+0
J718 CONN, HEADER, 6P, P2.54, DIP, ST, M, L=8.54 2101-3393+0
J724 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376+1
J725 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376+1
J728 SOCKET, EUFRO, BLOCK, 3P, P5, STRAIGHT,
GREEN
2113-3144+0
J729 SOCKET, EUFRO, BLOCK, 3P, P5, STRAIGHT,
GREEN
2113-3144+0
J742 CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409+0
J743 CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409+0
J760B CONNECTOR, PIN, HEADER, 4P, P2.54, ST, F 2101-3294+0
J761B CONNECTOR, PIN, HEADER, 4P, P2.54, ST, F 2101-3294+0
VR705 VR, ROTARY, 20BKX1, 20%, V, L=15, 18 TEETH,
CTR
4751-226E+0
VR706 VR, ROTARY, 20BKX1, 20%, V, L=15, 18 TEETH,
CTR
4751-226E+0
Miscellaneous
Reference
Designator
Description
V
endor Part Number Note
D702 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D703 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D704 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D705 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D706 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D707 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D717 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
Z700 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM
(RLZTE-116.2B)
4837-6V21+3
Z701 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM
(RLZTE-116.2B)
4837-6V21+3
Z704 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM
(RLZTE-116.2B)
4837-6V21+3
Reference
Designator
Description
V
endor Part Number Note
UF704 IC, NJM2068M-#ZZZB, DUFAL, OP, AMP 3130-6890+0
UF705 IC, NJM2068M-#ZZZB, DUFAL, OP, AMP 3130-6890+0
UF706 IC, NJM2068M-#ZZZB, DUFAL, OP, AMP 3130-6890+0
UF709 IC, NJM2068M-#ZZZB, DUFAL, OP, AMP 3130-6890+0
UF711 IC, 16-CH, DEMULTIPLEXER, 74HC4067M96, SO24,
TEXAS
3132-3021+0
UF712 IC, 8BIT, SHIFT, REGISTER, 74HC166, SO-16 3132-3281+0
UF715 IC, ANALOG-SW, DG211BDY-E3, SOIC-16 3133-0661+0
