Bose PowerShare PS602P Service Manual

33
ELECTRICAL PART LIST
Capacitors (continued)
Inductors and Ferrite Beads
Reference
Designator
Description Part Numbe
r
Note
L300 CORE, FERRITE, EQ20, LOW PROFILE 326426-0010
L301 INDUCTOR, BALANCED OUT, PQ26/25 753038-0010
L400 CORE, FERRITE, EQ20, LOW PROFILE 326426-0010
L401 INDUCTOR, BALANCED OUT, PQ26/25 753038-0010
T300 CORE, FERRITE, EQ20 326424-0010
T400 CORE, FERRITE, EQ20 326424-0010
Diodes
Reference
Designator
Description Part Numbe
r
Note
D100 SCHTKY, SC70, 30V, SINGLE 268381-001
D101 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D102 SWITCHING, SOD123, 1N4148W 257662
D103 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D104 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D105 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D106 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D107 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D108 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D201 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D202 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D206 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D207 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D208 SCHTKY, SC70, 30V, SINGLE 268381-001
D209 SCHTKY, SC70, 30V, SINGLE 268381-001
D300 SCHTKY, SC70, 30V, SINGLE 268381-001
D301 SCHTKY, SC70, 30V, SINGLE 268381-001
D302 SCHTKY, SC70, 30V, SINGLE 268381-001
D303 SCHTKY, SC70, 30V, SINGLE 268381-001
D304 SCHTKY, SC70, 30V, SINGLE 268381-001
D305 SCHTKY, SC70, 30V, SINGLE 268381-001
D306 SCHTKY, SC70, 30V, SINGLE 268381-001
D307 SCHTKY, SC70, 30V, SINGLE 268381-001
D308 SCHOTTKY, 1A, 30V, SOD123 317122-001
Amplifier PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description Part Numbe
r
Note
C485 X7R, 0603, 200V, 10%, 1000pF, COMM 718875-102K2D
C486 X7R, 1210, 200V, 10%, 220nF 327916-224K
C487 X7R, 1210, 200V, 10%, 220nF 327916-224K
C488 FILM, 15mm LS, BULK, 10%, 250Vdc, 0.47uF 354214-474IKB
C489 X7R, 1210, 200V, 10%, 220nF 327916-224K
C490 X7R, 1210, 200V, 10%, 220nF 327916-224K
C491 C0G, 1206, 100V, 5%, 0.047uF 354973-473J
C492 X7R, 1210, 200V, 10%, 220nF 327916-224K
C493 X7R, 1210, 200V, 10%, 220nF 327916-224K
C494 X7R, 1210, 200V, 10%, 220nF 327916-224K
C495 X7R, 1210, 200V, 10%, 220nF 327916-224K
C496 X7R, 1210, 200V, 10%, 220nF 327916-224K
C497 X7R, 1210, 200V, 10%, 220nF 327916-224K
C498 C0G, 0603, 50V, 5%, 430pF 188454-431
