Bose PowerShare PS602P Service Manual

35
ELECTRICAL PART LIST
Diodes (continued)
Transistors
Reference
Designator
Description Part Numbe
r
Note
Q100 BPLR, N, 40V, 200mA, SOT23 146819
Q101 BPLR, P, 40V, 200mA, SOT23 148596
Q102 BPLR, N, 40V, 200mA, SOT23 146819
Q103 BPLR, N, 40V, 200mA, SOT23 146819
Q104 BPLR, N, 40V, 200mA, SOT23 146819
Q105 BPLR, N, 40V, 200mA, SOT23 146819
Q106 BPLR, P, 40V, 200mA, SOT23 148596
Q204 BPLR, N, 40V, 200mA, SOT23 146819
Q205 BPLR, N, 40V, 200mA, SOT23 146819
Q300 BPLR, N, 40V, 200mA, SOT23 146819
Q301 BPLR, N, 40V, 200mA, SOT23 146819
Q302 BPLR, N, 40V, 200mA, SOT23 146819
Q303 BPLR, N, 40V, 200mA, SOT23 146819
Q304 BPLR, P, 40V, 200mA, SOT23 148596
Q305 BPLR, N, 40V, 200mA, SOT23 146819
Q306 BPLR, P, 40V, 200mA, SOT23 148596
Q307 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q308 NPN, LO SAT, 30V, 6A, SOT89 326375-0010
Q309 MFET, N-CH, 3.5A, 30V, SOT-23 362339-0010
Q310 MFET, N-CH, 60mA, 200V, SOT-23 354011-0010
Q311 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q312 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q313 NPN, LO SAT, 30V, 6A, SOT89 326375-0010
Q314 MFET, N-CH, 3.5A, 30V, SOT-23 362339-0010
Q315 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q316 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q317 NPN, LO SAT, 30V, 6A, SOT89 326375-0010
Q318 MFET, N-CH, 3.5A, 30V, SOT-23 362339-0010
Q319 NPN, LO SAT, 30V, 6A, SOT89 326375-0010
Q320 MFET, N-CH, 3.5A, 30V, SOT-23 362339-0010
Q321 MFET, N-CH, 60mA, 200V, SOT-23 354011-0010
Q322 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q323 MFET, N-CH, 60mA, 200V, SOT-23 354011-0010
Q324 MFET, N-CH, 60mA, 200V, SOT-23 354011-0010
Q325 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q326 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q327 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q328 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q329 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q330 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q331 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q332 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q333 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Amplifier PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description Part Numbe
r
Note
ZR205 ZENER, 7.5V, 250mW, 1%, SOT-23 135247-1236
ZR206 ZENER, 7.5V, 250mW, 1%, SOT-23 135247-1236
ZR207 ZENER, 7.5V, 250mW, 1%, SOT-23 135247-1236
ZR300 ZENER, 10.V, 225MW, 5%, SOT-23 135247-5240
ZR400 ZENER, 10.V, 225MW, 5%, SOT-23 135247-5240
