Bose PowerShare PS602P Service Manual

42
ELECTRICAL PART LIST
Capacitors (continued)
SMPS PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description
V
endor Part
Number
Note
C272 CE, 16V, 470uF, 20%, RLT, 10X12.5, 105C, LOW,
ESR
157D-477MSXTR
C273 CC, 50V, 0.47uF, 10%, 0805, 1.25X2, X7R 150F-474KBD
C274 CC, 500V, 0.022uF, 10%, 1206 150L-223KCF
C275 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C276 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C277 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C278 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C279 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C280 CE, 35V, 47uF, 20%, RLT, 6.3X11, 105C, RX,
NOVER
157Q-476MLUTU
C282 CM, 630V, 0.1uF, 10%, RB, 17X16X10, P15,
FARATRONIC
153M-104K654
C283 CM, 630V, 0.1uF, 10%, RB, 17X16X10, P15,
FARATRONIC
153M-104K654
C284 CC, 50V, 1uF, 10%, 0805 150F-105KBD
C285 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C286 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C287 CC, 250V, 0.1uF, 10%, X7R, 1206, 1.6X3.2 150R-104KCF
C288 CC, 250V, 0.1uF, 10%, X7R, 1206, 1.6X3.2 150R-104KCF
C289 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C290 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C293 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C294 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C295 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C296 CE, 25V, 470uF, 20%, RLT, 10X16, 105C, RX,
NOVER
157E-477MS5TU
C297 CE, 16V, 470uF, 20%, RLT, 10X12.5, 105C, LOW,
ESR
157D-477MSXTR
C298 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C299 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C300 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C306 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C307 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C308 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C310 CER2, 1206, X7R, 50V, 100nF, PM10, R 150F-104KCF
C311 CER2, 1206, X7R, 50V, 100nF, PM10, R 150F-104KCF
C312 CC, 630V, 0.1uF, 10%, 1812, X7R 150M-104KHF
C313 CC, 50V, 0.47uF, 10%, 0805, 1.25X2, X7R 150F-474KBD
C314 CC, 500V, 0.022uF, 10%, 1206 150L-223KCF
C315 CC, 630V, 0.1uF, 10%, 1812, X7R 150M-104KHF
C316 CC, 250V, 220pF, 10%, RL, 8.4X6, X7R 150R-221KPK 3
C317 CC, 250V, 220pF, 10%, RL, 8.4X6, X7R 150R-221KPK 3
C318 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C319 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C324 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C325 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C326 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C327 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
