Bose PowerShare PS602P Service Manual

45
ELECTRICAL PART LIST
SMPS PCB Assembly, PS602/PS602P/PS604
Miscellaneous
Integrated Circuits (continued)
Reference
Designator
Description
V
endor Part
Number
Note
U205 PHOTOCOUPLER, EL817S1, S1 4818-17S1 3
U206 IC, REGULATOR, 5V, LM78L05ACM, SO-8 3131-3390
U207 IC, PFC, CONTROLER, IR1155S, SO8 3132-9880
U208 IC, POWER, NCP1271, SO-8, ONSEMI 3132-806111
U209 IC, LLC, SMPS, UCC25600, SOIC-8 3132-8371
U210 IC, REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-769116
U211 IC, REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-769116
U212 PHOTOCOUPLER, EL817S1, S1 4818-17S1 3
U213 IC, LM317T, REGULATOR, ST 3130-5610
U214 IC, REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-769116
U215 IC, REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-769116
Reference
Designator
Description
V
endor Part
Number
Note
Clamp SCREW, MACHINE, PAN, M3X8, CROSS-RECESS,
BZ
2900-3008
Clamp CLAMP, IC, SUS301, T=1, NATURAL, 3/4H 4136-0932
F200 FUSE, T6.3A, 250V, 8X8.5VDE/PSE/CCC, RLT,
LITTLEFUSE
5120-1158L 3
HS200 WASHER, METAL, ID, 3.3, 0D8, T=0.5 2600-3005
HS200 NUT, HEX, M3X22X5.4, YZ 2640-3022
HS200 SCREW, M3X10, W/S&F, WASHER, (BLK) 2900-3010
HTS 120 70 SCREW, MACHINE, BIND, HEAD, M3X8, CROSS-
RECESS, BZ
2904-3008
Htsink IC HEATSINK, IC, 25.4X12.7X30, AL, PLATE,
MSMGMA100
5401-0181
J201 12P, ST.WAFER, P=2.5, COULOMB 2102-121S
J202 WAFER, 3PIN, P=3.96 2101-3065
J203 WAFER, 3P, P7.92/11.88, STRAIGHT 2101-3097
J204 JM24182-2P, WAFER 2101-9120
J205 JM24182-2P, WAFER 2101-9120
L=120 HEATSINK, SMPS, 14X30, L120, AL-EXT, ANODIZE,
BLACK
5401-0701
L=70 HEATSINK, SMPS, 14X30, L=70, AL-EXT, ANODIZE,
BLACK
5401-0702
NTC200 THERMISTOR, NTC, 5R, 20%, 240V, 6A, 200C, RL,
THINKING
5202-0045 3
Silicon PAD INSULATN-SHEET, SIL-PAD, 800, 55X22 3101-0961
T200 TRANS, PWR, 385V/80V, 600W, 4A, ER40 1806-4235 3
T201 CHOKE, COMMON, MODE, 10MH, MIN, 5A,
SPACERS, 2.5MM, AT
1805-0090 3
