ELECTRICAL PART LIST
Resistors (continued)
DSP PCB Assembly, PS602
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
R633 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991
R634 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991
R635 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991
R636 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991
R645 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R646 RMG, 1/10W, 499 OHM, 1%, 0805 4720-4990
R647 RMG, 1/16W, 1.58K, 1%, 0603 4723-1581
R648 RMG, 1/10W, 1.62K, 1%, 0603 4720-1621
R649 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R650 RMG, 1/16W, 150 OHM, 1%, 0603 4723-151AR
R651 RMG, 1/16W, 5.6K, 1%, 0603/1608 4723-562A
R652 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
R653 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
R654 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
R655 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
Reference
Designator
Description
V
endor Part
Number
Note
C400 CC, 6.3V, 22uF, 10%, 1206, 3.2X1.6 150B-226KCF
C401 CC, 6.3V, 22uF, 10%, 1206, 3.2X1.6 150B-226KCF
C402 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C403 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C404 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C405 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C406 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C407 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C408 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C409 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C410 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C412 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C413 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C414 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C415 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C416 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C417 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C418 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C419 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C421 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C422 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C423 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C425 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C426 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C427 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C428 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C429 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C430 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C431 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C432 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C433 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C434 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C435 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
