Bose PowerShare PS602P Service Manual

81
ELECTRICAL PART LIST
Resistors (continued)
DSP PCB Assembly, PS604
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
R651 RMG, 1/16W, 5.6K, 1%, 0603/1608 4723-562A
R652 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
R653 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
R654 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
R655 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
Reference
Designator
Description
V
endor Part
Number
Note
C400 CC, 6.3V, 22uF, 10%, 1206, 3.2X1.6 150B-226KCF
C401 CC, 6.3V, 22uF, 10%, 1206, 3.2X1.6 150B-226KCF
C402 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C403 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C404 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C405 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C406 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C407 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C408 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C409 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C410 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C412 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C413 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C414 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C415 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C416 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C417 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C418 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C419 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C420 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C421 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C422 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C423 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C425 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C426 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C427 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C428 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C429 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C430 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C431 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C432 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C433 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C434 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C435 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C436 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C437 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C438 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C439 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C440 CE, 25V, 100uF, 20%, 6.3X7.7, SMD 157E-107MLO
C441 CE, 25V, 100uF, 20%, 6.3X7.7, SMD 157E-107MLO
C442 CC, 25V, 10uF, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C443 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C444 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
