20
|
ENG
CONNECT SOURCES
CONNECT SOURCES TO CHANNEL 1 AND 2
Channels 1 and 2 are for instruments and microphones. The channel inputs are suited
for a wide range of input types and have the proper gain staging to minimize noise
when channel volume is set for your desired output level.
1. Connect your instrument or microphone to the channel input using the
appropriate cable.
2. Adjust channel volume, treble, bass, and reverb to your desired levels
(see page 23).
3. Optionally, you can also apply a ToneMatch preset to optimize the sound of your
instrument or microphone (see page 27).

Table of Contents

Other manuals for Bose S1 PRO+

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Bose S1 PRO+ and is the answer not in the manual?

Bose S1 PRO+ Specifications

General IconGeneral
TypeHandheld Public Address (PA) system
Handle(s)Yes
Product colorBlack
Housing materialAluminium, Polypropylene (PP)
Storage temperature (T-T)-20 - 49 °C
Operating temperature (T-T)0 - 45 °C
Bluetooth range9 m
Bluetooth version5.0
Connectivity technologyWired & Wireless
6.35 mm (1⁄4-inch) input2
Charging time5 h
AC input voltage100 - 240 V
Battery capacity5500 mAh
Power source typeAC, Battery
AC input frequency50/60 Hz
Battery life (max)11 h
Number of mixer channels3 channels
Speaker type2-way
Number of speakers-
Frequency range- Hz
RMS rated power- W
Weight and Dimensions IconWeight and Dimensions
Depth279.8 mm
Width240 mm
Height332.6 mm
Weight6500 g
