Bose S1 PRO+ User Manual

BATTERY
55
|
ENG
CHARGE A WIRELESS TRANSMITTER
Using the charging ports
Fully insert the wireless transmitter into the wireless transmitter charging port for
either Channel 1 or 2 until you hear or feel a click.
If the system is powered on, on the channel display, a battery icon with a lightning
bolt next to it briefly appears to indicate that the transmitter battery is charging. A
lightning bolt icon then appears in the upper-right corner of the display. When the
transmitter is fully charged, the lightning bolt icon disappears (see page 60).
VOLUME
NOTE: If the system is connected to power, the AC (mains) power connection charges
the transmitter. If the system is operating on battery power, the system battery
charges the transmitter.
Using a wall charger or computer
NOTE: Use this product only with an agency-approved LPS power supply that meets
local regulatory requirements (e.g., UL, CSA, VDE, CCC).
1. Connect one end of a USB-C cable (not provided) to the USB-C port on the top of
the wireless transmitter.
2. Connect the other end to a USB-A wall charger or computer.
The power light glows solid white (see page 62). When the transmitter is fully
charged, the power light turns o.

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
