Bose S1 PRO+ User Manual

62
|
ENG
WIRELESS TRANSMITTER STATUS
The power light and connection light on the wireless transmitter show the
transmitter status.
MUTE
MUTE
Power light Connection light
POWER LIGHT
Shows the power, battery level, charging, and error status of the transmitter.
LIGHT ACTIVITY SYSTEM STATE
Blinks white 4 times
(when powering on)
75% - 100% battery level
Blinks white 3 times
(when powering on)
50% - 75% battery level
Blinks white 2 times
(when powering on)
25% - 50% battery level
Blinks white 1 time
(when powering on)
10% - 25% battery level
Solid white Powered on or charging
Blinking red Transmitter battery low
Solid red Error - contact Bose customer service

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
