Bose S1 PRO+ User Manual

69
|
ENG
TROUBLESHOOTING
TRY THESE SOLUTIONS FIRST
If you experience problems with the system:
• Make sure the system is connected to a live AC (mains) outlet (see page 18).
• Power the system o and then on (see page 18).
• Secure all cables.
• Check the state of the status lights (see page 57).
• Check for and download any available software updates (see page 67).
OTHER SOLUTIONS
If you couldn’t resolve your issue, see the table below to identify symptoms and
solutions to common problems. You can also access troubleshooting articles, videos,
and other resources at: support.Bose.com/S1ProPlussupport.Bose.com/S1ProPlus
If you’re unable to resolve your issue, contact Bose customer service.
Visit: worldwide.Bose.com/contactworldwide.Bose.com/contact
System
SYMPTOM SOLUTION
System doesn’t
power on
System battery may be in protection mode or discharged.
Connect the system to AC (mains) power.
Plug the power cord into a dierent AC (mains) outlet.
If the power cord is connected to a power strip or surge protector,
try plugging it directly into the AC (mains) outlet.
Unplug the power cord and remove the system battery
(see page 65). Wait 30 seconds, then replace the battery and
firmly plug the power cord back in to the AC (mains) outlet.
Reset the system (see page 77). Power on again.

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
