Bose S1 PRO+ User Manual

WIRELESS TRANSMITTER CONTROLS
38
|
ENG
CONNECT A PAIRED WIRELESS TRANSMITTER TO AN
AUDIO SOURCE
1. Power on the system (see page 18).
2. Press the back of the wireless transmitter and release so that it slides out of the
wireless transmitter charging port. Remove it from the charging port.
On the channel display, a battery icon briefly appears to indicate the transmitter
battery level.
3. Connect the transmitter to your audio source.
4. Power on the transmitter (see page 39). After a few seconds, a transmitter icon
appears on the channel display and the connection light on the transmitter glows
solid blue to indicate that the transmitter is connected (see page 63).
VOLUME
5. If you’re using the Bose Wireless Mic/Line Transmitter, change between mic and
line input settings if necessary to match the input requirements of your source
(see page 40).

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
