Bose S1 PRO+ User Manual

TROUBLESHOOTING
70
|
ENG
SYMPTOM SOLUTION
Intermittent or no audio
from an instrument or
audio source connected
by an input cable
Make sure your instrument or audio source is firmly connected to
the channel input.
Increase the volume on the instrument or audio source and
the system.
Check that the signal/clip lights are lit to confirm that the system
detects an audio signal from the source.
Connect your instrument or audio source to a dierent amplifier
to confirm the source is working.
Connect a dierent instrument or audio source.
Try using another input cable to connect the instrument or audio
source to the system.
If you’re using a condenser microphone, make sure to connect
it to a phantom power supply (such as a preamplifier or mixing
console) before connecting it to the system.
Unplug the power cord and remove the system battery
(see page 65). Wait 30 seconds, then replace the battery and
firmly plug the power cord back in to the AC (mains) outlet.
Reset the system (see page 77).
System doesn’t connect
to Bluetooth device
On your device:
• Turn the Bluetooth feature o and then on again.
• Delete the system from the Bluetooth list on your device,
including any duplicate listings labeled LE (Low Energy).
Connect again (see page 64).
Connect another mobile device (see page 64).
Clear the system device list (see page 64). Connect again.
Intermittent or no audio
from a Bluetooth device
Play audio from a dierent application or music service.
Move your mobile device closer to the system (30 ft or 9 m) and
away from any interference or obstructions.
Stop other audio or video streaming applications.
Make sure your mobile device supports Bluetooth connections.
Restart your mobile device.
Connect a dierent mobile device (see page 64).

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
