17 / 30
3. Press and hold the „Up” button if you want to raise the intensity.
If you want to lower the intensity, press and hold down the “Down”
button.
4. While holding down the „Up“ or „Down“ button, tap the „Flash“
button corresponding to the DMX channel of the scene you wish to
modify until you reach the desired intensity value read from the
display. Then you may tap the “Flash” buttons until you are satisfied
with the new scene.
5. Repeat steps 2, 3 and 4 until all the steps have been modified.
6. Exit „Edit“mode.
4.3. Running
4.3.1. Running chase programs
1. Tap the „Mode Select“button to select „SHNX<>SCENE“mode
indicated by the red LED.
2. Tap the „Page” button to select the correct page the program you
wish to run is located.
3. Push Master Fader B to its maximum position (fully down).
