4.1.3. Program Scenes
1. Record Enable.
2. Select the „1-48 Single“mode by tapping the „Mode Select“button.
This will give you control of all 24 channels as you program.
Be sure that “Master A&B” are both set at maximum. (Master A is at its
maximum in the fully up position, while Master B is as its maximum in
the fully down position.)
3. Create a desired scene using channel faders 1-48. At 0% or DMX 0,
these faders should be at 0 position, and at 100% or DMX 255, these
faders should be at 10 position.
4. Once the scene is satisfactory, tap the „Record” button to program
the scene as a step into the memory.
5. Repeat Step 3 and 4 until all desired steps have been programmed
into memory.
You may program up to 1000 steps into memory.
6. Select a chase bank or scene master to store your program. Tap the
“Page” button to select a page (Page 1-4) to store your scenes.
7. Press a „Flash“button between 25-48 while holding down the
„Record“button. All LED will flash indicating the scenes have been
programmed into memory.
