5. MIDI operation & DMX channel setup
5.1. MIDI
5.1.1. Setting MIDI IN
1. Tap the „Flash” button 1 three times while holding down the
„Record” button, the display reads „CHI” indicating MIDI IN channel
setup is available.
2. Tap the “Flash” button numbered from 1-16 to assign MIDI IN
channel 1-16, the relevant channel LED lights indicating MIDI IN
channel is set.
5.1.2. Setting MIDI OUT
1. Tap the „Flash” button 2 three times while holding down the
“Record” button, the display reads “CHO” indicating MIDI OUT channel
setup is available.
2. Tap the „Flash“ button numbered from 1-16 to assign MIDI OUT
channel 1-16, the relevant channel LED lights indicating MIDI OUT
channel is set.
