9 Control System and Programs 9
9.2 Program Sequence
9.2
Machine P 12/P15 P 1 P 2 P 3 P 4 P 5 P 6 P 7 P 8 P 9
Pump tank 1 to tank1 00:05 00:05 00:05 00:05 00:05
Pumping from tank 1 00:40 00:55 00:55
Pumping from tank 2 00:30 00:25 00:30 00:55
Pump circuit 02:00 02:00 02:00 02:00
Spinning to distillation 01:00 01:30 01:30
Pumping from tank 1 01:30* 01:30* 01:10 01:30
Pumping from tank 2 00:45 01:00 01:30 01:30* 01:30 00:30* 01:00*
Filtration 03:30 04:30 05:00 03:00 05:00 05:00
Pump circuit 03:00* 03:00* 02:00
Pumping to tank 1 00:30 00:30 00:30 00:45
Pumping to tank 2
Pumping out to still 00:45 00:45 00:30
Spinning to tank 1 02:30 02:00 02:30
Spinning to tank 2
Spinning to distillation 02:30 01:00 01:30 02:00 02:00
Pumping to tank 1 00:15 00:45
Pumping to tank 2
Pumping to distillation. 00:15 00:45 00:45
Pumping from tank 2 01:30 00:45* 00:45
Pump circuit 02:00 03:00 03:00
Pumping to tank 2 00:30 00:15
Pumping to distillation 00:15
Spinning to tank 2 02:30 01:00
Spinning to distillation 02:30
Pumping to tank 2 00:45 00:45
Pumping to distillation 00:45
Tumbling 00:30
Spraying 04:00 04:00
Tumbling 03:30 03:30
Predrying without heat 03:00 03:00 03:00 03:00
Drying cage outlet 50°C
(122°F)
12:00 12:00 12:00 12:00 12:00 14:00 14:00
Drying cage inlet: 60°C
(140 °F)
09:00 09:00
Drying time controller X X X X X X X X X
Reduction ** from
without Slimsorba to
02:00
06:00
02:00
06:00
02:00
06:00
02:00
06:00
02:00
06:00
02:00
06:00
02:00
06:00
02:00
06:00
02:00
06:00
Reduction with Slimsorba 03:00 03:00 03:00 03:00 03:00 03:00 03:00 03:00 03:00
Adsorption (only with
Slimsorba)
06:00 06:00 06:00 06:00 06:00 06:00 06:00 06:00 06:00
Total time without from
Slimsorba to
(without drying time
controller)
23:00
27:00
28:00
32:00
38:55
42:55
21:30
25:30
33:30
37:30
25:45
29:45
29:00
33:00
32:45
36:45
27:00
31:00
Total time with Slimsorba
(without drying time
controller)
30:00 35:00 45:55 28:30 40:30 32:45 36:00 39:45 34:00
* Dosing P04/P05: with solvent cooling = soft programs
** temp. controlled
X plus standstill times because of the drying controller
The times given above correspond to the program sequences at the time of printing.
We reserve the right to make any procedural changes to times and program sequences in the interest of technical progress.
P12
