Pre Start Inspection and Operation
3.23
6. Shut the engine off.
DO NOT go underneath the attachment when it is raised.
7. Rotate the attachment lock pins (Item 1, Figure 3–34) into the locked position
securing the attachment to the machine.
Figure 3-34 Attachment Locks in Locked Position
8. Start the engine and raise the attachment off the ground. Visually inspect the
bottom edge of the attachments mounting plate to make sure that both of the
attachment lock pins are securely holding the attachment in position.
9. Shut off the engine.
10. Relieve hydraulic pressure stored in the hoses. NOTE: To relieve pressure in
high ow side, depress push buttons located on the pressure relief block (see
Figure 3–37).
11. Attach the hydraulic hoses to the quick connects. See Figure 3–36.
NOTE: There are two hydraulic hoses that need to be connected. The quick
connect system prevents you from incorrectly connecting the hydraulic hoses, but
both hoses need to be connected for the attachment to operate.
Make sure that the engine has been shut off before beginning this procedure.
CAUTION
