REAR PANEL
1) GAS INLET
2) WATER OUTLET
3) ACTIVATED CARBON FILTER
4) GAS OUTLET
5) HOUSING FOR Nox SENSOR
6) O2 SENSOR
7) COALESCENT FILTER
8) ENGINE TEMPERATURE SENSOR INPUT
9) ENGINE RPM SENSOR INPUT
10) SOCKET FOR RS-232 SERIAL LINK
11) 12 Vdc POWER SUPPLY AND COMMUNICATION WITH omniBUS
INSTRUMENTS
