C-2 100-214-239 Rev. A
Accessories Parts List
Continuous Flow,
Glass Rosett
Cooling Cell
Cooling cell for continuous circulation of the
substance being processed. The cell is
equipped with intake and output connections
for continuous processing and a double cham-
ber for cooling. Normally, adequate cooling is
achieved by connection to the cold water tap,
or by using a closed-circuit system. An ice/salt
water solution will maintain a temperature
below 0°C. Borosilicate glass construction
allows observation during treatment.
Not suited for difficult cells.
201-123-004
Sealed
Atmosphere
Treatment
Chambers
Used for batch treatment of infectious
materials. Input and output connections allow
filling and emptying without breaking the air-
tight seal and permit processing with an inert
gas. Stainless steel.
• 3-10 ml 101-021-001
• 6-15 ml 101-021-002
• 25-50 ml 101-021-003
Same as above 101-021-001 series, but with
cooling water jacket.
• 3-10 ml 101-021-004
• 6-15 ml 101-021-005
• 25-50 ml 101-021-006
Flat Tip Replacement for 1/2" horn, 1/4"-20 thread 101-148-013
Tapered Microtips
For processing small volumes. Attaches to
standard tapped disruptor horn. Tip amplitude
is 3-1/2 times greater than that of standard
horn. Recommended for difficult applications,
such as spores, fungi, yeast, muscle and
connective tissue. Excellent results on
volumes ranging from 3 to 20ml in a
comparatively short time.
• 1/8" diameter 101-148-062
• 3/16" diameter 101-148-069
• 1/4" diameter 101-148-070
Item Description
Branson EDP
Number
