Branson Digital Sonifier 250 - Front Panel Controls

100-214-239 Rev. A 6-7
Front Panel Controls
Digital Sonifier
Figure 6.1 Digital Sonifier front panel, showing a Ready mode display including Amplitude
CAUTION
j Do not use a sharp or pointed object to press the front panel controls. The soft-touch mem-
brane front panel can be permanently damaged.
Digital Sonifier
®
PRESET ID#__
TIME=_:__:__ hr/m/s
MAX. TEMP=___._
° C
AMPLITUDE= 17 %
