6-32 100-214-239 Rev. A
Operation
Parameter Entry - Pulse Temperature
The Pulse Temperature is the lower temperature parameter of the
Pulse/Pause mode
temperature range.
Entering a value for the Pulse Temperature enables the Pulse/Pause mode; clearing this value disables this
mode.
CAUTION
j Setting the PULSE TEMP parameter to a numeric value will activate the Pulse/Pause Mode
process. This can cause the system to operate in an On and Off fashion, which can cause the
ultrasonics to be suspended for a period of time, and then reactivate to continue a process
cycle without warning.
Do not handle the Horn or Converter if the Pulse/Pause Mode is activated and running, and
ensure the process cycle is Stopped before touching the Horn, or injury could occur.
Take this action… To get this result…
Use the Up and Down arrow keys, if
necessary, to display the line showing
the Pulse Temp parameter.
PresstheLine Selectkey thatcorresponds
to Pulse Temp.
To Next Page
