6-26 100-214-239 Rev. A
Operation
Parameter Entry - Time
The Time parameter, if used, identifies the time duration of an experiment, in hours, minutes and seconds, dur-
ing which ultrasonic vibrations are active and are putting energy into y our experiment. The experiment will stop
when the Time entry has elapsed. Time may also be used as a Limit.
CAUTION
j Setting the MAX TEMP and TIME parameters together can cause the system to operate in a
temperature-limiting fashion, which can cause ultrasonics to be suspended briefly, and then
reactivate to continue a process cycle without warning.
Do not handle the Horn or Converter if using MAX TEMP and TIME in the Temperature Mode,
and ensure the process cycle is Stopped before touching the Horn, or injury could occur.
Take this action… To get this result…
Use the Up and Down arrow keys, if
necessary, to display the line showing the
Time parameter.
PresstheLine Selectkey thatcorresponds
to Time.
To Next Page
