Bredel 25 - Page 61

A
C
B
5. Loosen the retaining bolt (A) of both pressing shoes (B). Remove the shims (C) if present.
A
B
6. Use two crow bars to remove the rotor (A). Position both crow bars behind the recesses (B) in
the rotor and push from the hub.
A
7. Dismount the retaining circlip (A) with the correct tool.
m-bredel-25-32-en-05 61
