12. Connect the pump to the electrical supply.
13. Switch on the electrical supply.
14. Jog the motor until the pressing shoe is positioned between the inlet and outlet ports.
15. Isolate the pump from the electrical supply.
16. Repeat the procedure for removing and fitting this second pressing shoe.
17. Refill the lubricant.
See also
Refer to "Torque figures" on page 85
Refer to "Shims specifications" on page 85
Refer to "Changing lubricant" on page 45
For the required quantity of lubricant, Refer to "Lubricant table pump" on page 83
Replacing the rotor, bearings, and seal ring
1. Remove the pump hose.
See also
Refer to "Changing the hose" on page 46
2. Isolate the pump from the electrical supply.
3. Remove the cover (B) by loosening the retaining bolts (A).
4. Check the sealing ring (C) is not damaged and replace it if necessary.
60 m-bredel-25-32-en-05
