6. Loosen the retaining bolt(s) (A) of the pressing shoe (B) a few turns. Fit the shims (C) or remove
them, until the correct number of shims is present. Tighten the retaining bolt of the pressing
shoe to the specified torque.
See also
Refer to "Torque figures" on page 85
7. Check the gasket (C) for damage and replace it if necessary.
8. Refit the cover (B). Make sure that the four bolts (A) are refitted and that they are tightened in
the correct order, diagonally opposite each other.
9. Connect the pump to the electrical supply.
10. Switch on the electrical supply.
11. Jog the motor until the pressing shoe is positioned between the inlet and outlet ports.
12. Isolate the pump from the electrical supply.
13. Repeat the procedure for this second pressing shoe.
14. Refill the lubricant.
See also
Refer to "Changing lubricant" on page 45
68 m-bredel-25-32-en-05
