11.2 Parts list
Overview
3
2
6
1
4
5
Pos. Description
1 Cover assembly. Refer to "Cover assembly" on the next page
2 Rotor assembly. Refer to "Rotor assembly" on page 92
3 Pump housing assembly. Refer to "Pump housing assembly" on page 94
4 Pump support assembly. Refer to "Pump support assembly" on page 97
5 Flange assembly. Refer to "Flange assembly" on page 99
6 Lubricant. Refer to "Lubricant" on page 102
