Brocade FastIron X Series Chassis Hardware Installation Guide 173
53-1001723-02
Power supply specifications
7
Figure 65 shows the power plug and connector for the SX-ACPWR-SYS and SX-ACPWR-POE power
supplies. The power cord is 2.5 meters in length.
FIGURE 65 AC power cable plug and input connector for SX-ACPWR-SYS and SX-ACPWR-POE
power supplies
Figure 66 shows the power plug for the SX-ACPWR2500-POE power supply.
FIGURE 66 AC power cable plug for SX-ACPWR2500-POE power supply
Figure 67 shows the DC connector for the SX-DCPWR-SYS and SX-DCPWR-POE power supplies.
FIGURE 67 DC power cables for SX-DCPWR-SYS and SX-DCPWR-POE power supplies
M
F
- 48 VDC Lead 48 RTN Lead
8 AWG Wire
Negative Terminal Screw
Terminal
Screw
Cover
Positive Terminal Screw
