Page #30 background imageLoading...
Page #30 background image
18 Brocade FastIron X Series Chassis Hardware Installation Guide
53-1001723-02
Hardware features
1
Built-in switch fabric module
The switch fabric module switches user packets from one interface module installed in the chassis
to another. On the FSX, the switch fabric module is built into the management module.
Console port
The Console port on the management module is a standard DB-9 serial connector through which
you can attach a PC or terminal to configure the system using the command line interface (CLI).
The Console port interfaces the control plane only and not the data plane.
Reset button
The reset button on the management module allows you to restart the system. The reset button is
recessed to prevent it from being pushed accidentally.
The reset button is located next to the console port on the management module.
FSX 800 and FSX 1600 management modules
The management modules for the FSX 800 and FSX 1600 are interchangeable between devices.
Standard management modules provide Layer 2 and base Layer 3 functionality only. Premium
management modules support full Layer 3 functionality.
NOTE
The FSX 800 and FSX 1600 management modules are dedicated, which means that you must
install them in the FSX 800 or FSX 1600 chassis only. If you attempt to install these management
modules in the FSX or other Brocade chassis, the chassis and modules will not function properly.
NOTE
You cannot intermix different management modules in the same FSX 800 or FSX 1600 chassis. The
management modules must be of like-kind.
NOTE
You cannot intermix IPv6 and IPv4 modules in the same FSX 800 or FSX 1600 chassis.
10/100/1000
Mbps Copper
Ports (
Square LED located on upper
left corner of upper copper
connector for upper copper
connector
Square LED located on upper
right corner of upper copper
connector for lower copper
connector
On (Green) A link is established with the remote
port.
Blinking The port is transmitting and receiving
traffic.
Off A link is not established with the
remote port.
1000 Mbps Fiber
Ports
Round LED located beneath
the fiber connectors
On (Green) A link is established with the remote
port.
Blinking The port is transmitting and receiving
packets.
Off A link is not established with the
remote port.
TABLE 5 FSX management module LEDs (Continued)
LED Description and Position State Meaning
