Stack unit slots for FCX stackable devices (Continued)TABLE 2
Device Slot 1 Slot 2 Slot 3
Brocade FCX 648-E and
Brocade FCX 648-I devices
with optional 4r-port 10 Gbps
SFP+ module
48 10/100/1000 Mbps RJ45 ports 4-port 10 Gbps SFP+
module on front panel
(optional module)
N/A
SFP interfaces
This section describes the network interfaces supported on FCX devices. For information about
supported SFP and SFP+ transceivers, refer to the following Brocade website:
http://www.brocade.com/downloads/documents/data_sheets/product_data_sheets/Optics_DS.pdf
SFP network interfacesTABLE 3
Interface Show Media Description
1000Base-BX-D M-GBXD
1000Base-BX-U M-GBXU
1000Base-LHA M-LHA
1000Base-LHB M-LHB
1000Base-LX M-LX
1000Base-LH M-LH
1000Base-SX M-SX
1000Base-T C
100Base-T C**
10Base-T C**
100Base-FX M-FX
Optional two-port 10 Gbps XFP uplink module
The Brocade FCX 624S, FCX 648S, FCX 624S-F, FCX 624S-HPOE, and FCX 648S-HPOE devices
include a slot on the front panel for a two-port 10 Gbps XFP uplink module. This module operates at
10 Gbps full duplex.
SFP interfaces
18 Brocade FCX Series Hardware Installation Guide
53-1002977-01
