Brooks 5850S - Page 27

27
Installation and Operation Manual
X-DPT-Profibus-Interface-eng
PN 541-C-068-AAG
November, 2008
Select adaptive control option
0 = Off
1 = Tune offset
20 byte 0..2 1
2 = Tune offset & span
21 byte n.a. 0 Extended user parameter
n.a. reserved
Mass Flow Meter
byte
#
bit
#
type Range
[dec]
default
[dec]
options description
Internal system parameter8byten.a.0
n.a. reserved
Select gas calibration
1 = curve 1
2 = curve 2
3 = curve 3
4 = curve 4
5 = curve 5
6 = curve 6
7 = curve 7
8 = curve 8
9 = curve 9
9 byte 1..10 1
10 = curve 10
Select gas calibration curve
Not used10 byte n.a. 0
n.a. reserved
Primary non fatal alarms
0 bit 1 0 = disabled, 1 = enabled Flow Sensor Error
1 bit 1 0 = disabled, 1 = enabled Temperature Sensor Error
2 bit 1 0 = disabled, 1 = enabled Analogue Output Error
3 bit 1 0 reserved
4 bit 1 0 = disabled, 1 = enabled Flow out of range
5 bit 1 0 = disabled, 1 = enabled Output out of range
6 bit 1 0 reserved
11
7 bit 0 0 reserved
Secondary non fatal alarms
0 bit 0 0 = disabled, 1 = enabled Low Flow Alarm
1 bit 0 0 = disabled, 1 = enabled High Flow Alarm
2 bit 0 0 = disabled, 1 = enabled Totalizer overflow
3 bit 0 0 reserved
4 bit 0 0 reserved
5 bit 0 0 reserved
6 bit 0 0 reserved
12
7 bit 0 0 reserved
Ambient non fatal alarms
0 bit 1 0 = disabled, 1 = enabled Temperature Too High
1 bit 1 0 = disabled, 1 = enabled Power Failure
2 bit 0 0 reserved
3 bit 0 0 reserved
4 bit 1 0 = disabled, 1 = enabled Temperature Too Low
5 bit 0 0 reserved
6 bit 0 0 reserved
13
7 bit 0 0 reserved
Not used14 byte n.a. 0
n.a. reserved
