Using the configurator and with the selected device, “S-series MFC”, the
parameters can be viewed in the configuration tool and adjusted against the
customer configuration of the device.
Not used15 byte n.a. 0
n.a. reserved
Select flow unit
0 = % Percent of full scale
1 = ml/sec Milliliter per second
2 = ml/min Milliliter per minute
3 = ml/hr Milliliter per hour
4 = l/sec Liter per second
5 = l/min Liter per minute
6 = l/hr Liter per hour
7 = m3/sec Cubic metre per second
8 = m3/min Cubic metre per minute
9 = m3/hr Cubic metre per hour
10 = ft3/sec Cubic feet per second
11 = ft3/min Cubic feet per minute
12 = ft3/hr Cubic feet per hour
13 = reserved
14 = reserved
15 = reserved
16 = g/sec Gram per second
17 = g/min Gram per hour
18 = g/hr Gram per hour
19 = kg/sec Kilogram per second
20 = kg/min Kilogram per minute
21 = kg/hr Kilogram per hour
22 = Lb/sec Pound per second
23 = Lb/min Pound per minute
16 byte 0..24 0
24 = Lb/hr Pound per hour
Select temperature unit
0 = Kelvin Temperature in Kelvin
1 = Celsius Temperature in Celsius
17 byte 0..2 1
2 = Fahrenheit Temperature in Fahrenheit
Select totalizer unit
0 = ml Milliliter
1 = Liter Liter
2 = m3 Cubic meter
3 = ft3 Cubic feet
4 = reserved
5 = reserved
6 = reserved
7 = reserved
8 = reserved
9 = reserved
10 = reserved
11 = reserved
12 = reserved
13 = reserved
14 = reserved
15 = reserved
16 = g Gram
17 = kg Kilogram
18 byte 0..18 1
18 = Lb Pounds
