2A 1 1/16" - 12SAE/MS (ONLY FOR 5853/63)
2B ½" TUBE COMPRESSION FITTINGS (ONLY FOR 5850/60/51/61/53/63)
2C 3/4" TUBE COMPRESSION FITTINGS (ONLY FOR 5853/63)
2D 1" TUBE COMPRESSION FITTINGS (ONLY FOR 5853/63)
2E ½" NPT(F) (ONLY FOR 5853/63)
2F 1" NPT(F) (ONLY FOR 5853/63)
2G 1½" NPT(F) (SEE OPTION "E") (ONLY FOR 5853/63/64)
2H ½" VCO (200 ln/min. max.) (ONLY FOR 5850/60/51/61/53/63)
2J 3/4" VCO (ONLY FOR 5853/63)
2K ½" VCR (200 ln/min. max.) (ONLY FOR 5850/60/51/61/53/63)
BROOKS SMART MASS FLOW PRODUCTS
SMART MASS FLOW METERS / CONTROLLERS
BASE MODEL NUMBER DESCRIPTION
MECHANICAL CONNECTIONS
2L DIN DN15PN40 (ONLY FOR 5853/63)
2M DIN DN25PN40 (ONLY FOR 5853/63)
2N DIN DN40PN40 (ONLY FOR 5853/63)
2O DIN DN50PN40 (ONLY FOR 5853/63)
2P ANSI ½" 150 LBS (ONLY FOR 5853/63)
2R ANSI ½" 300 LBS (ONLY FOR 5853/63)
2S ANSI 1" 150 LBS (ONLY FOR 5853/63)
2T ANSI 1" 300 LBS (ONLY FOR 5853/63)
2U ANSI 1½" 150 LBS (ONLY FOR 5853/63)
2V ANSI 1½" 300 LBS (ONLY FOR 5853/63)
2W ANSI 2" 150 LBS (ONLY FOR 5853/63)
2X ANSI 2" 300 LBS (ONLY FOR 5853/63)
2Y 1" VCO (ONLY FOR 5853/63)
2Z 3/4" VCR (ONLY FOR 5853/63)
9Z SPECIFY
O-RING/VALVE SEAT MATERIAL
AVITON
B BUNA (NOT FOR 5853)
C PTFE/KALREZ (KALREZ FOR SENSOR O-RINGS AND VALVE SEAT)
D KALREZ (NOT FOR 5853)
E PTFE O-RINGS / EPDM VALVE SEAT
M KALREZ O-RINGS / METAL VALVE SEAT
Z SPECIFY
VALVE TYPE
0 METER ONLY (NO VALVE)
1 NORMALLY CLOSED (5850/51 SERIES)
2 NORMALLY CLOSED (PRESS.DIFF. >2BAR. 5853 SERIES)
3 NORMALLY CLOSED (PRESS.DIFF. <2BAR. 5853 SERIES)
4 NORMALLY OPENED (5850 ONLY)
5 NORMALLY CLOSED, 5850 SERIES, 300 BAR
9 SPECIFY
