Installation and Operation Manual
X-DPT-Profibus-Interface-eng
PN 541-C-068-AAG
November, 2008
BROOKS SMART MASS FLOW PRODUCTS
SMART MASS FLOW METERS / CONTROLLERS
BASE MODEL NUMBER DESCRIPTION
ELECTRICAL INPUT/OUTPUT
INPUT OUTPUT
A 0-5Vdc 0-5 Vdc & 0-20mA (INCL. RS 232, 9600 BDS)
B 4-20mA 4-20 mA & 1-5Vdc (INCL. RS 232, 9600 BDS)
C 0-20 mA 0-20mA & 0-5Vdc (INCL. RS 232, 9600 BDS)
D 1-5Vdc 1-5 Vdc & 4-20m
A
(INCL. RS 232, 9600 BDS)
E DIG. COMM. DIG. COMM. + 0 - 5 Vdc
F DIG. COMM. DIG. COMM. + 4 - 20 mA
G DIG. COMM. DIG. COMM. + 0 - 20 mA
H DIG. COMM. DIG. COMM. + 1 - 5 Vdc
I DIG. COMM. DIGITAL COMMUNICATION (ONLY)
Z SPECIFY
COMMUNICATION / BAUDRATE
A 0 ANALOG I/O AND RS 232 & 9600 BAUD
B* RS232
C* RS485
D0
PROFIBUS-DP (
PNO CERTIFIED
, 831-A-023 and 541-C-068-AAG)
E0
PROFIBUS-DP (not
CERTIFIED, 831-A-021 and 541-C-062-AAG)
F* CARDEDGE CONNECTOR (ONLY 0-5 I/O & COMMUNICATION)
G* CARDEDGE CONNECTOR (ONLY 0-5 I/O & COMMUNICATION) RS-232
H* CARDEDGE CONNECTOR (ONLY 0-5 I/O & COMMUNICATION) RS-485
*1 38400 Baud
*2 19200
*3 9600
*4 7200
*5 4800
*6 3600
*7 2400 * BOTH HAVE TO BE SPECIFIED
*8 1200
INTERCONNECTION CABLE
A NO CABLE
B MATING CONNECTOR ONLY
C 3m ROUND CABLE
D 6m ROUND CABLE
E 3m ROUND CABLE INCLUDING COMMUNICATION CABLE
F 6m ROUND CABLE INCLUDING COMMUNICATION CABLE
Z SPECIFY
ENHANCEMENTS
A STANDARD RESPONSE:< 1 SEC (5850/51) < 3 SEC (5853) [1].
B FAST RESPONSE (SPECIFY VALUES .... SEC.) [1]
C LINEAR RAMP (SPECIFY VALUES ....%/SEC.) [1]
D FLOW OUTPUT DAMPING (SPECIFY VALUES .... SEC.) [1]
