CALIBRATION
0 UNCALIBRATED
DEDUCT
1 STANDARD CALIBRATION INCLUDED
2 STORAGE OF MULTIPLE CAL. CURVES; ADD PER AVAILABLE
CALIBRATION GAS
9 SPECIFY
POWER SUPPLY INPUT
A ± 15 Vdc
B + 24 Vdc = (Standard selection)
C + 15 Vdc only
Z SPECIFY
AREA CLASSIFICATION
1 SAFE AREA
2 CERTIFIED FOR USE IN ZONE 2
9 SPECIFY
5850S/BC 1H A 1 A B3 C A 1 B 1 = TYPICAL MODEL NUMBER
