Brother DCP-J100

3-72
Confidential
Assembling Note When attaching the Carriage PCB ASSY, route the Carriage flat cable
as shown in the figure of Section 7-5 in this chapter.
(3_051L)
Head/carriage unit
Lock spring
Carriage
PCB ASSY
Head flat cable
Carriage flat cable
Remove by pulling the lock
Carriage PCB ASSY
Opening
Film
Upper cover
Boss
Head flat cable
Head/carriage unit
Carriage PCB ASSY
