3-55
Confidential
(8) Remove the Taptite bind B M3x10 screw, and then remove the Registration front sensor
PCB ASSY from the Actuator holder ASSY.
Fig. 3-50
Taptite bind B M3x10
Registration front sensor PCB ASSY
Actuator holder ASSY
