Brother HL-2170W - Harness Routing

3-7
Confidential
6. HARNESS ROUTING
1 FUSER UNIT
2 FG HARNESS
PS PCB unit
Fuser unit
Eject sensor PCB ASSY
Laser unit
FG harness
Main PCB ASSY
<Left side>
<Back side>
