3-18
Confidential
8.3.2 OUTER CHUTE ASSY
(1) Release the Boss to remove the Outer chute ASSY from the Main body.
Fig. 3-10
Boss (Fuser cover ASSY)
Boss (Fuser cover assy)
Outer chute ASSY
Outer chute ASSY
Outer chute ASSY
1a
1a1a
1b
