Brother HL-2170W - Inner Chute Assy

3-22
Confidential
8.5 INNER CHUTE ASSY
(1) Remove the two Taptite bind B M4x12 screws, and then remove the Inner chute ASSY
from Main body.
Fig. 3-15
Taptite bind B M4x12
Inner chute ASSY
