Brother MFC-7320 Service Manual

App. 1-64
Confidential
<WSW61>
• Selectors 1 through 8:Change rate of the CCD scanning light intensity to judge to be
stable. (Not used.)
The light intensity of the CCD unit is changed widely immediately after the light source is
on, that influences scanning density. Therefore, the first scanning after the light source is
off and on is started after the change rate of the CCD light intensity is stabilized in the
definite range. These selectors set the change rate to start the scanning operation above. If
you want to start scanning immediately even if the image quality is not good, set the rate to
high.
Long / short time mode:
The selectors are divided between the long and short time modes depending on the
scanning resolution and black and white or color mode. The long time mode is selected in
color scanning at 600dpi or more, or in black and white scanning at 1200dpi. The short time
mode is selected in other scanning conditions than the above.
Selector No. Function Setting and Specifications
1
I
4
Change rate of the CCD
scanning light intensity to judge
to be stable in the long time
mode (Not used.)
No. 1 2 3 4
0000: 1% (Default)
0001: 0.5%
0010: 3%
0011: 5%
0100: 10%
0101: 15%
0110: 20%
1111: 100% *
* (Scans immediately after the light
source ON)
5
I
8
Change rate of the CCD
scanning light intensity to judge
to be stable in the short time
mode (Not used.)
No. 5 6 7 8
0000: 5% (Default)
0001: 1%
0010: 3%
0011: 10%
0100: 15%
0101: 20%
0110: 30%
1111: 100% *
* (Scans immediately after the light
source ON)

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
