Brother MFC-7320 Service Manual

App. 1-65
Confidential
<WSW62>
• Selectors 1 through 4:Change rate of the CCD light intensity for scanning pages
compensation (Not used.)
The light intensity of the CCD unit may be changed (decreased, especially), and difference
of density may appear among the scanning pages if continuous copying or scanning is
implemented from the ADF for a long time. To prevent the above, in simplex copying or
scanning from the ADF, the machine checks the change rate of the light intensity in every
page. Then, it takes the compensation data again if the rate is over the set value. These
selectors set the change rate of the light intensity to control such operations.
Change rate for simple compensation:
Change rate when compensating the pages using the standard data in the machine
memory without moving the CCD unit to the designated position for scanning of the
compensation data.
Change rate for regular compensation:
Change rate when compensating the pages with moving the CCD unit to the designated
position for scanning of the compensation data and obtaining the data actually.
For duplex scanning, this setting is not used since the machine takes the compensation
data of every page again.
Selector No. Function Setting and Specifications
1
I
4
Change rate of the CCD
light intensity for scanning
pages compensation
(Not used.)
Change rate Change rate
No.1234 for simple for regular
compensation compensation
0000: 3% 10% *
0001: 3% 7%
0010: 3% 15%
0011: 3% 20%
0100: 3% 25%
0101: 5% 10%
0110: 5% 15%
0111: 5% 20%
1000: 5% 25%
1001: 7% 15%
1010: 7% 20%
1011: 7% 25%
1100: 10% 15%
1101: 10% 20%
1110: 10% 25%
1111: 15% 30%
* Default
5
6
Selection of judging function
for simple scanning pages
compensation (Not used.)
No. 5 6
00:
Judges according to the change rate
0 1: Not judges
1 0: Judges every page
7
8
Selection of judging function
for regular scanning pages
compensation (Not used.)
No. 7 8
00:
Judges according to the change rate
0 1: Not judges
1 0: Judges every page

Brother MFC-7320 Specifications

General

Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	11 cpm
Faxing	Mono faxing
Fax memory	400 pages
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
Standard interfaces	USB 2.0
Dimensions (WxDxH)	428 x 396 x 304 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows Vista, XP (32 & 64 bit); Windows 2000, Mac OS X 10.2.4 en recenter Linux printer driver
Power consumption (standby)	75 W
Power consumption (PowerSave)	9 W
Power consumption (average operating)	320 W
Display	LCD
Market positioning	Home & office
Media weight (tray 1)	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Bundled software	ScanSoft Paperport 11 SE+OCR, Newsoft Presto!, PageManager7 (Mac)
Package weight	14.900 g
Grayscale levels	256
Input color depth	24 bit
Sustainability certificates	ENERGY STAR
